High Gradient Magnetic Separator
Feed Size : 1000mm
Capacity : 4-10t/h
Application Fields : Suitable for ferrous metals, nonferrous metals, rare metals, non-metal recycling, etc
Introduction : We supply High Gradient Magnetic Separator,jaw crusher,impact crusher,ball mill,etc. High gradient magnetic separator is mainly used for recycling weak magnetic metal ores.
High gradient magnetic separator is mainly used for recycling weak magnetic metal ores.
High gradient magnetic separator application:
Ferrous metal: recycling feint hematite, hematite, limonite, siderite, ilmenite, manganese,cetc.
Nonferrous metal: separating wolframite, garnet, etc.
Rare metal: recycling tantalum niobite, iron lepidolite, monazite, xenotime, etc.
Nonmetal: decontaminating quartz, feldspar, kaolin and refractory material.
Main technical parameters of high gradient magnetic separator:
|
Model |
SSS-I-1000 |
SSS-I-1200 |
SSS-I-1500 |
SSS-I-1750 |
SSS-I-2000 |
|
Separating ring diameter(mm) |
1000 |
1200 |
1500 |
1750 |
2000 |
|
Rated excitated power(kw) |
25 |
35 |
45 |
63 |
72 |
|
Capacity(t/h) |
4-10 |
10-20 |
20-35 |
30-50 |
40-75 |
|
Rated backgroudn field
intensity (t) |
1.0 |
1.0 |
1.0 |
1.0 |
1.0 |
|
Feeding size(mm) |
0.01-2 |
0.01-2 |
0.01-2 |
0.01-2 |
0.01-2 |
|
Motor power(kw) |
4.5 |
6.6 |
8.4 |
13.5 |
16.5 |
|
Weight(kg) |
8000 |
12000 |
21000 |
38000 |
51000 |
